Coffee Roasters 1 Kg
“Start your professional journey with the 1kg Coffee Roaster from ETKAN Syrian Company for Industry. Perfect for retail shops and sample roasting due to its compact, attractive design. As the best coffee roaster manufacturer, we offer industrial precision in a small footprint, ideal for labs and stores to roast fresh coffee in front of customers.”
Default features
1- Sample spoon and sampling bottle
2- The peel compartment is separate
3- Simultaneous roasting and cooling
4- The cooling system is developed by a high-performance turbine
5- Digital temperature and control indicator
Additional options
1- Transporting pills by air or mechanical feeder
2- Automatic seed discharge
3- Separate smoke filter
4- Computer operation
Gas Unit
- Gas Unit: Equipped for 4 cylinders, each with a separate valve
- Regulator: Industrial pressure regulator to control gas pressure entering the machine
- Gauges:
◦ Pressure gauge for the unit (Bar)
◦ Pressure gauge for the burner (mm bar)
Chaff Collector
• Equipped with a thermally insulated peeling (cyclone) device.
• Designed to break up air currents and improve the separation process to ensure a clean final product.
• Equipped with maintenance doors.
• Equipped with water sprayers for spark control.
Control Mechanism
Available Control Systems:
o Advanced digital control system via high-resolution digital display
o Manual control system via traditional buttons
Operating Options:
o Fully automatic control for greater precision and control
o Semi-automatic control for greater flexibility
Electrical Specs
• Voltage: 220/380V – 50-60Hz
• Maximum Power: 3 kW
• Electrical Safety: A suitable circuit breaker is recommended to ensure safe operation.• Electrical Panel: Separate from the machine for ease of operation and maintenance.
• Equipped with an inverter for speed control and overload protection of the motors.
Loading Mechanism
Loading Options (Client Choice):
◦ Green bean pneumatic loader (Air).
◦ Mechanical conveyor loader.
Motors
- Country of Origin: High-quality Turkish-made motors. The machine can also be equipped with German or Italian motors according to customer requirements, ensuring reliable performance and a long service life.
- Number of Motors:
- 3 motors for balanced and stable performance:
Three 1 HP motors.
One 0.5 HP motor.
- 3 motors for balanced and stable performance:
Cooling Mechanism
- Cooling Tray: Made of Stainless Steel (S.S 304) for cleanliness and easy maintenance.
- Features:
◦ Separate fan to accelerate cooling .
◦ Thermally insulated motor for efficiency.
◦ Special maintenance door for cleaning.
Insulation & Paint
- Thermal Insulation: Turkish ceramic insulation withstands 1500°C
- Paint: Electrostatic.
- Main Color: Black (Customizable upon request).
